Minimum pressure requirements
0.1 bar (Gravity) 1 bar (HP/Combi)
-
Maximum pressure requirements
1 bar (Gravity) 5 bar (HP/Combi)
-
Aqualisa SmartValve™ inlet fitting connections15mm push fit
-
Valve inlet centres48mm
-
Inlet supply positionsHot right, cold left
-
Aqualisa SmartValve™ outlet fitting connection15mm push fit
-
Permissible Aqualisa SmartValve™ siting locationLoft, airing cupboard, under bath
-
Supply temperature
Cold inlet temperature 1˚C (minimum)
Cold inlet temperature 15˚C (maximum)
Hot inlet temperature 65˚C (maximum)
-
Water system
HP / Combi / Gravity
-
Features
One touch start/stop control
LED display indicates when pre-selected temperature has been reached
Boost button for enhanced flow
Wi-Fi & App compatible – control your product with your smart phone and smart home device e.g. Alexa, Google
App functions include start/stop, shower timer, user dashboard, usage tracker and help & support
Aqualisa SmartValve™
Compatible with wired remote control
105mm, 4 spray patterns (adjustable head) including eco-spray option
-
ColourChrome
-
Guarantee period
5-year guarantee – shower unit
2-year guarantee – shower head and kit
-
Approvals
CE Marking
UKCA
BEABS
