Description
The Aqualisa Quartz Classic Concealed Digital Shower with Bath Filler & Adjustable Head is the complete smart shower and bath solution. The digital diverter switches between the bath filler and the 105mm adjustable shower head — filling the bath or showering at your pre-set temperature, all controlled via one-touch interface, Wi-Fi app, or Alexa and Google Home. The Aqualisa SmartValve™ is sited remotely for a completely clean bathroom installation.
Add a secondary start/stop control for extra convenience.
Bath Filler & Shower in One System
The integrated digital diverter switches seamlessly between the bath filler and the adjustable shower head — giving you smart control over both your bath and shower from a single concealed valve. Pre-set your preferred bath temperature and step away while it fills to exactly the right temperature.
One-Touch Smart Control with Boost
Simple push-button one-touch start/stop with an LED display that indicates when your pre-selected temperature has been reached. The boost button delivers enhanced flow on demand for rinsing or when extra pressure is needed.
Wi-Fi & App Compatible
Connect via Wi-Fi for full smartphone control through the Aqualisa app. Features include remote start/stop, shower timer, user dashboard, usage tracker, and help & support. Also compatible with Alexa and Google Home smart home devices.
Aqualisa SmartValve™
The concealed Aqualisa SmartValve™ can be sited remotely — in a loft, airing cupboard, or under bath — keeping all mechanical components out of the bathroom for a completely clean installation. Connections are 15mm push-fit throughout.
Key Features
- Bath filler outlet — smart temperature-controlled bath filling
- Digital diverter — switch between bath filler and adjustable head
- One-touch start/stop control
- LED display — shows when target temperature is reached
- Boost button for enhanced flow
- Wi-Fi & app compatible (iOS & Android)
- Alexa & Google Home compatible
- App: start/stop, timer, dashboard, usage tracker
- Aqualisa SmartValve™ — remote siting in loft, airing cupboard, or under bath
- 105mm adjustable head — 4 spray patterns including eco-spray
- Compatible with wired secondary remote control
- CE, UKCA & BEAB approved
- 5-year guarantee (shower unit)
- 2-year guarantee (shower head & kit)
Specifications
- Min. pressure: 0.1 bar (Gravity) / 1 bar (HP/Combi)
- Max. pressure: 1 bar (Gravity) / 5 bar (HP/Combi)
- Inlet connections: 15mm push-fit
- Outlet connections: 15mm push-fit
- Valve inlet centres: 48mm
- Inlet supply: Hot right, cold left
- SmartValve™ siting: Loft, airing cupboard, under bath
- Cold inlet temp: 1–15°C
- Hot inlet temp: max 65°C
- Head: 105mm adjustable, 4 spray patterns inc. eco-spray
- Finish: Chrome
- Approvals: CE, UKCA, BEAB
- Brand: Aqualisa
- Range: Quartz Classic
- SKU: QZD.A1.BV.DVBTX.23
- Guarantee: 5yr (unit) / 2yr (head & kit)
Professional installation by a qualified plumber is required. SmartValve™ must be sited in an accessible location for servicing. Bath filler outlet requires appropriate bath installation.
