Description
The Aqualisa Quartz Classic Concealed Digital Shower with Fixed Ceiling Head & Adjustable Head delivers the ultimate dual-outlet smart shower experience. A dramatic ceiling-mounted fixed head provides a true overhead rainfall effect, while the 105mm adjustable handset offers flexible directed showering — switchable via digital diverter. One-touch start/stop, boost button, Wi-Fi and app control, and the trusted Aqualisa SmartValve™ complete the package.
Fixed Ceiling Head — The Definitive Rainfall Experience
The ceiling-mounted fixed head delivers a true overhead rainfall experience from directly above — the most immersive shower installation possible. Ideal for wet rooms, large shower enclosures, and premium bathroom refurbishments where a statement installation is the goal.
Digital Diverter — Ceiling Head & Adjustable Handset
The integrated digital diverter switches seamlessly between the fixed ceiling head and the 105mm adjustable handset — use the ceiling head for an immersive rainfall experience, or the handset for flexible, directed showering. Both outlets are controlled from the same intuitive touch interface.
One-Touch Smart Control with Boost
Simple push-button one-touch start/stop with an LED display that indicates when your pre-selected temperature has been reached. The boost button delivers enhanced flow on demand — ideal for rinsing or when extra pressure is needed.
Wi-Fi & App Compatible
Connect via Wi-Fi for full smartphone control through the Aqualisa app. Features include remote start/stop, shower timer, user dashboard, usage tracker, and help & support. Also compatible with Alexa and Google Home smart home devices.
Aqualisa SmartValve™ — Remote Siting
The concealed Aqualisa SmartValve™ can be sited remotely — in a loft, airing cupboard, or under bath — keeping all mechanical components out of the bathroom for a completely clean installation. All connections are 15mm push-fit throughout.
Key Features
- Fixed ceiling-mounted head — true overhead rainfall experience
- Digital diverter — switch between ceiling head and adjustable handset
- 105mm adjustable head — 4 spray patterns including eco-spray
- One-touch start/stop control with LED temperature display
- Boost button for enhanced flow on demand
- Wi-Fi & app compatible (iOS & Android) — start/stop, timer, dashboard, usage tracker
- Alexa & Google Home compatible
- Aqualisa SmartValve™ — remote siting in loft, airing cupboard, or under bath
- Compatible with wired secondary remote control
- CE, UKCA & BEAB approved
- 5-year guarantee (shower unit) / 2-year guarantee (shower head & kit)
- Concealed installation — clean, uncluttered bathroom finish
Technical Specification
| Specification |
High Pressure / Combi |
Gravity / Low Pressure |
| SKU |
QZD.A1.BV.DVFC.23 |
QZD.A2.BV.DVFC.23 |
| Barcode |
5023942293595 |
5023942293922 |
| Price |
£999.00 |
£1,099.00 |
| Min. pressure |
1 bar |
0.1 bar |
| Max. pressure |
5 bar |
1 bar |
| Inlet connections |
15mm push-fit |
| Outlet connections |
15mm push-fit |
| Valve inlet centres |
48mm |
| Inlet supply |
Hot right, cold left |
| SmartValve™ siting |
Loft, airing cupboard, under bath |
| Cold inlet temp |
1–15°C |
| Hot inlet temp |
Max 65°C |
| Outlets |
Fixed ceiling head + 105mm adjustable handset (diverter) |
| Finish |
Chrome |
| Country of Origin |
United Kingdom |
| Approvals |
CE, UKCA, BEAB |
| Guarantee |
5yr (unit) / 2yr (head & kit) |
| Brand |
Aqualisa |
| Range |
Quartz Classic |
Complete the Quartz Classic Range
Frequently Asked Questions
What is the difference between the High Pressure/Combi and Gravity/Low Pressure variants?
The High Pressure/Combi variant (QZD.A1.BV.DVFC.23) is designed for mains-pressure and combination boiler systems with a minimum of 1 bar. The Gravity/Low Pressure variant (QZD.A2.BV.DVFC.23) is designed for gravity-fed and low-pressure systems (immersion heater) with a minimum of just 0.1 bar. If you’re unsure which system you have, check with your plumber before ordering.
How does the diverter work?
The digital diverter switches water flow between the fixed ceiling head and the adjustable handset at the touch of a button. Only one outlet operates at a time.
Can I use both heads at the same time?
No — the diverter switches between the two outlets; only one can be used at a time.
Does ceiling head installation require special preparation?
Yes — ceiling head installation requires appropriate ceiling structure and waterproofing. Professional installation by a qualified plumber is required.
Where does the SmartValve™ go?
The SmartValve™ can be sited remotely — in a loft, airing cupboard, or under the bath — keeping all mechanical components out of the bathroom for a clean finish. It must remain accessible for servicing.
Is this shower compatible with smart home devices?
Yes — the Quartz Classic is compatible with Alexa and Google Home, and can be controlled via the Aqualisa app on iOS and Android.
Can I add a secondary control?
Yes — the Quartz Classic is compatible with the Aqualisa Quartz Classic Smart Secondary Start/Stop Control, allowing you to start and stop your shower from a second location.
What is the guarantee?
5 years on the shower unit and 2 years on the shower head and kit.
Can I order if the item shows as out of stock?
Yes — we operate on a pre-order basis for out-of-stock items. Please contact us at customerservice@bubblegumbathrooms.co.uk or call 01603 381095 to confirm lead times before ordering.
