Description
The Aqualisa Quartz Classic Concealed Digital Shower with Bath Filler & Adjustable Head is the complete smart shower and bath solution. The integrated digital diverter switches seamlessly between the bath filler and the 105mm adjustable shower head — filling the bath or showering at your pre-set temperature, all controlled via one-touch interface, Wi-Fi app, or Alexa and Google Home. The Aqualisa SmartValve™ is sited remotely for a completely clean bathroom installation.
Bath Filler & Shower in One System
The integrated digital diverter switches seamlessly between the bath filler and the adjustable shower head — giving you smart control over both your bath and shower from a single concealed valve. Pre-set your preferred bath temperature and step away while it fills to exactly the right temperature.
One-Touch Smart Control with Boost
Simple push-button one-touch start/stop with an LED display that indicates when your pre-selected temperature has been reached. The boost button delivers enhanced flow on demand — ideal for rinsing or when extra pressure is needed.
Wi-Fi & App Compatible
Connect via Wi-Fi for full smartphone control through the Aqualisa app. Features include remote start/stop, shower timer, user dashboard, usage tracker, and help & support. Also compatible with Alexa and Google Home smart home devices.
Aqualisa SmartValve™ — Remote Siting
The concealed Aqualisa SmartValve™ can be sited remotely — in a loft, airing cupboard, or under bath — keeping all mechanical components out of the bathroom for a completely clean installation. All connections are 15mm push-fit throughout.
Key Features
- Bath filler outlet — smart temperature-controlled bath filling
- Digital diverter — switch between bath filler and adjustable shower head
- 105mm adjustable head — 4 spray patterns including eco-spray
- One-touch start/stop control with LED temperature display
- Boost button for enhanced flow on demand
- Wi-Fi & app compatible (iOS & Android) — start/stop, timer, dashboard, usage tracker
- Alexa & Google Home compatible
- Aqualisa SmartValve™ — remote siting in loft, airing cupboard, or under bath
- Compatible with wired secondary remote control
- CE, UKCA & BEAB approved
- 5-year guarantee (shower unit) / 2-year guarantee (shower head & kit)
- Concealed installation — clean, uncluttered bathroom finish
Technical Specification
| Specification |
High Pressure / Combi |
Gravity / Low Pressure |
| SKU |
QZD.A1.BV.DVBTX.23 |
QZD.A2.BV.DVBTX.23 |
| Barcode |
5023942293588 |
5023942293809 |
| Price |
£940.00 |
£1,035.00 |
| Min. pressure |
1 bar |
0.1 bar |
| Max. pressure |
5 bar |
1 bar |
| Inlet connections |
15mm push-fit |
| Outlet connections |
15mm push-fit |
| Valve inlet centres |
48mm |
| Inlet supply |
Hot right, cold left |
| SmartValve™ siting |
Loft, airing cupboard, under bath |
| Cold inlet temp |
1–15°C |
| Hot inlet temp |
Max 65°C |
| Head |
105mm adjustable, 4 spray patterns inc. eco-spray |
| Outlets |
Bath filler + adjustable shower head (diverter) |
| Finish |
Chrome |
| Approvals |
CE, UKCA, BEAB |
| Guarantee |
5yr (unit) / 2yr (head & kit) |
| Brand |
Aqualisa |
| Range |
Quartz Classic |
Complete the Quartz Classic Range
Frequently Asked Questions
What is the difference between the High Pressure/Combi and Gravity/Low Pressure variants?
The High Pressure/Combi variant (QZD.A1.BV.DVBTX.23) is designed for mains-pressure and combination boiler systems with a minimum of 1 bar. The Gravity/Low Pressure variant (QZD.A2.BV.DVBTX.23) is designed for gravity-fed and low-pressure systems (immersion heater) with a minimum of just 0.1 bar. If you’re unsure which system you have, check with your plumber before ordering.
How does the bath filler work with the shower?
The integrated digital diverter allows you to switch between the bath filler and the adjustable shower head. You can pre-set your preferred temperature and divert to the bath filler to fill the bath hands-free, then switch to the shower head when ready. Only one outlet operates at a time.
Does this shower require professional installation?
Yes — professional installation by a qualified plumber is required. The SmartValve™ must be sited in an accessible location for future servicing, and the bath filler outlet requires appropriate bath installation.
Where does the SmartValve™ go?
The SmartValve™ can be sited remotely — in a loft, airing cupboard, or under the bath — keeping all mechanical components out of the bathroom for a clean finish.
Is this shower compatible with smart home devices?
Yes — the Quartz Classic is compatible with Alexa and Google Home, and can be controlled via the Aqualisa app on iOS and Android.
Can I add a secondary control?
Yes — the Quartz Classic is compatible with the Aqualisa Quartz Classic Smart Secondary Start/Stop Control, allowing you to start and stop your shower from a second location.
What is the guarantee?
5 years on the shower unit and 2 years on the shower head and kit.
Can I order if the item shows as out of stock?
Yes — we operate on a pre-order basis for out-of-stock items. Please contact us at customerservice@bubblegumbathrooms.co.uk or call 01603 381095 to confirm lead times before ordering.
