Description
The Sondrio Rimless Short Projection Close Coupled WC is designed for bathrooms where every millimetre counts. At just 600mm deep and 360mm wide, it is an ideal choice for cloakrooms, compact en-suites, and any space where a standard projection toilet simply won't fit — without sacrificing quality or aesthetic. The rimless bowl eliminates hidden ledges for effortless hygiene. A flexible 4-way soil coupling (straight out, straight down, left, or right) makes installation straightforward in a wide range of configurations. The wrap-over soft-close seat, cistern, and all fittings are included. Backed by a lifetime guarantee on sanitaryware.
Key Features
-
Short projection — 600mm depth — ideal for cloakrooms, compact bathrooms, and en-suites
-
Rimless bowl — no hidden ledges; superior hygiene and easier cleaning than traditional rimmed pans
-
4-way flexible soil coupling — straight out, straight down, left, or right; suits a wide range of installations
-
Complete set — pan, cistern, wrap-over soft-close seat, and all fittings included
-
Push button dual flush — left-hand cistern inlet
-
Open back design — conceals pipework against the wall
-
Compact 360mm width — space-efficient footprint
-
Vitreous china construction — durable, hygienic, easy to clean
-
Lifetime guarantee on sanitaryware; 2-year guarantee on seat and hinges
Technical Specification
-
SKU: BGBP117074 | EAN: 5054913612251
-
Brand: Aqua Elegance — Sondrio Collection
-
Type: Rimless short projection close coupled WC
-
Finish: White
-
Material: Vitreous china
-
Total height (with cistern): 800mm
-
Width: 360mm
-
Depth (projection): 600mm
-
Flush operation: Push button (dual flush)
-
Cistern type: Close coupled
-
Cistern inlet: Left-hand position
-
Soil coupling: 4-way — straight out / straight down / left / right
-
Soil pipe spigot to wall: 245mm
-
Seat: Wrap-over soft-close (included)
-
Comfort height: No (standard height)
-
Rimless: Yes
-
Country of origin: CN
-
Sanitaryware guarantee: Lifetime
-
Seat & hinges guarantee: 2 years
-
Dimension tolerance: ±2% on dimensions over 75mm; ±4% on dimensions under 75mm
What's in the Box
- Sondrio rimless short projection close coupled WC pan
- Close coupled cistern with push button flush
- Wrap-over soft-close toilet seat
- All fittings and fixings
Complete the Sondrio Range
Explore other WC options and accessories from the Sondrio collection:
Use This WC with the Saturn Vanity Pack
This is the WC included in the Aqua Elegance Saturn 500mm Wall Hung Vanity Unit & Toilet Pack — a complete bathroom bundle combining the Saturn vanity unit, basin, and this Sondrio WC. If you want a larger vanity, buy this WC separately alongside the 600mm or 800mm Saturn vanity unit.
Frequently Asked Questions
What is a short projection WC?
Short projection refers to the depth of the WC pan from the wall to the front of the pan. A short projection WC is shallower than a standard pan — the Sondrio measures just 600mm deep, compared to a typical standard projection of 680–720mm. This makes it ideal for cloakrooms, compact bathrooms, and en-suites where floor space is limited.
What is a rimless WC?
A rimless WC has no inner rim around the top of the pan. Traditional pans have a rim that can harbour bacteria, limescale, and waste residue, making them difficult to clean thoroughly. A rimless pan allows water to flush directly across the entire inner surface in a powerful, directed stream, providing a more hygienic clean with every flush and making the pan significantly easier to maintain.
What soil pipe connections does this WC support?
The Sondrio short projection WC supports 4-way flexible soil coupling: straight out (horizontal), straight down (vertical), left, or right. This makes it compatible with a wide range of bathroom plumbing configurations. The soil pipe spigot is 245mm from the wall.
Is the seat included?
Yes — a wrap-over soft-close toilet seat is included as standard. If you prefer a slimmer, lower-profile seat, the Sondrio Slim Soft Close Seat is available to purchase separately.
What is the cistern inlet position?
The cistern inlet is left-hand position. Ensure your water supply connection is on the left side of the cistern before ordering. If your supply is on the right, please call us on 01603 381095 to discuss options.
Is this a comfort height WC?
No — this is a standard height WC. If you require a raised seat height for easier use, see the Sondrio Rimless Comfort Height Close Coupled WC.
What guarantee does this WC come with?
The Sondrio sanitaryware (pan and cistern) carries a lifetime guarantee. The seat and hinges carry a 2-year guarantee.
Can I order if the item shows as out of stock?
Yes — you can still place your order even if this item shows as out of stock. We will fulfil your order as soon as stock is replenished and will keep you updated on lead times.
